For forming fabric: TMR3000

Weaving width : up to 16m
Max. speed : 120 ppm (for 14m loom)
Max. beat-up force : 3000 kg/m
Weft density : 10-120 /cm
Weft diameter : 0.10-0.60 mm

Main drive : VMD servo drive
Sley motion : By double cams
Dobby type : DISCO dobby; Staubli 2688S
Harness system : Staubli，for max. 28 frames
Weft insertion : Texo Posi-Grip rapier; 8-12 sets
Warpbeam : 2-4 warpbeams; servo driven
